Spiral welded pipe mill

The spiral welded pipe production line was designed to manufacture spiral welded pipes, either from the same size of the steel strips to different diameters of pipes or from different widths of steel strips to the seam diameter of pipes. The process flow of the production line: Loading coil → Uncoiling → End straightening and feeding → Five-roll flattening → End cutting and butt welding → Disc edge cutting → Strip surface cleaning → Finish edge milling → Delivering → Pre-bending → Guide board device → Forming → Inner welding → Outer welding (Inner and outer welding seam automatic tracking system) → Sizing → Centralized guide → Pipe cutting → Repair welding → X-ray testing → Hydrostatic testing → End facing and beveling → Ultrasonic testing → Weighing and measuring → Antisepticising → Mark spraying → Storage We have many models spiral welded pipe production lines. The produced spiral welded pipes satisfied API-5L, GB9711.1-1997, SY/T5037-2000 standards and other related. They could be used for oil and natural gas pipeline, low-pressure water pipe, city gas pipeline, thermal electric power network, urban construction pile pipe, industrial structure tube and so on, to meet the needs of various industries and the needs of different occasions. Specifications and parameters list: ModelOuter diameter of welded pipe(mm)Thickness of welded pipe(mm)Width of strip(mm)LH426219 4265.0 8.0400 750LH529219 5295.0 10.0400 800LH630219 6305.0 10.0450 1000LH820219 8206.0 12.7500 1500LH1020219 10206.0 12.7500 1500LH1220219 12206.0 16.0600 1500LH1420219 14206.0 16.0800 1900LH1620219 16206.0 20.0800 1900LH1820508 18208.0 20.01100 2000LH2540508 25408.0 25.41200 2000LH3048508 30488.0 25.41200 2000
